Digital icebergs, by an amazing visionary.

One of the largest sculptures ever produced using Additive Manufacturing.

May 6, 2014

Iñigo Manglano-Ovalle met with CIDEAS in late 2005.  He had acquired the 3D topographical scans of an Iceberg, which he personally visited off the coast of Canada. Iñigo had envisioned an enourmous sculpture for a scheduled exhibit at the Art Institute of Chicago.

The Scanned data was interpolated into STL CAD files, which became 531 independent joints and 3D printed by CIDEAS. These printed joints were then used in conjunction with; 1,062 anodized tubes and over 3,000 pins, which in turn, were assembled by Iñigo and his team, to create the final piece.

It was imperative that the 531 joints used to produce the final piece were strong and extremely accurate, due to the overall size and span of the final Iceberg.

$article/title

Iñigo's first sculpture was designed to hang from the ceiling and initially had incorporated 31 SLS parts for the internal joints, eventually, those were replaced in future sculptures, due to the difficult nature of drilling into the rigid, hard Nylon material.

To date, five sculptures have been produced, three of which span 2 stories in height and have a diameter of approximately 20 ft.

Unfortunately, in 2005 very few people, let alone journalists, understood the importance of Iñigo's work. Ironically he was highlighting the technology soon to be exploited in a new format, he was truly a contemporary in an undiscovered field.



  • Liverpool England

    Built with durable ABS plastic joints (twice the thickness as the Chicago sculpture). This impressive piece, was on display for a full year outdoors, able to withstand 120 mph winds.

  • The "Contemporary Wing" at The Art Institute of Chicago

    Two Stories tall and nearly 20 feet in diameter, Inigo's first sculpture was installed in 2005. A sister piece currently resides indefinitely at the Cleveland Clinic.

  • Berlin

    Here in 2007, passerby's don't realize the nature of construction and importance of the 3D printed pieces within the sculpture they see before them.
